WavePhoenix Replacement Receiver for WaveBird GameCube Controllers with Virtual Pairing and Updateable Firmware

The WavePhoenix adapter replaces a missing WaveBird GameCube receiver, allowing you to use a WaveBird controller through a compact receiver with virtual pairing. The package contains one receiver set up on channel 1.

Key Features

• Press the receiver pairing button, then hold X + Y on the WaveBird controller to pair.
• The onboard LED blinks in pairing mode and stays solid after successful pairing.
• Virtual pairing replaces the original receiver channel wheel.
• Firmware v0.9.2 is preinstalled, and the project provides a firmware update guide.

Specifications

• Compatibility: WaveBird GameCube controller.
• Package: one WavePhoenix receiver adapter.
• Dimensions: 18.5×27.5×20mm.
• Project: open-source WavePhoenix.

Firmware Updates

The linked mini-receiver guide uses the rf-bm-bg22c3 firmware build. It describes over-the-air updates with WavePhoenix Web in Google Chrome on a Bluetooth-equipped computer or Android phone, and SWD flashing as another method. Over-the-air updates require the bootloader. The guide uses .gbl files for over-the-air updates and .hex files for SWD flashing. Follow the instructions for your receiver before updating.
