Nano A000005 Breadboard-Friendly Development Board with ATmega328P, Mini-B USB and 16MHz Clock

The Arduino Nano A000005 is a compact, breadboard-friendly ATmega328P development board. It provides functionality similar to the Arduino Duemilanove in a smaller layout, using Mini-B USB and omitting a DC power jack.

Key Features

• ATmega328P microcontroller operating at 16MHz.
• 22 digital I/O pins, including six PWM outputs.
• Eight analog input pins.
• Mini-B USB connection for programming and power.
• Compact 18 × 45mm PCB for breadboard projects.
• Compatible with Arduino IDE and the Arduino development ecosystem.

Specifications

• Brand and model: Arduino Nano
• Product code: A000005
• Microcontroller: ATmega328P
• Operating voltage: 5V
• Recommended input voltage: 7–12V
• Flash memory: 32KB, including 2KB bootloader
• SRAM: 2KB
• EEPROM: 1KB
• Clock: 16MHz
• DC current per I/O pin: 20mA
• Power consumption: 19mA
• Dimensions: 18 × 45mm
• Weight: 7g
