M162C-2L-PB10 Monocular Biological Microscope with Dual LED Light, Coarse and Fine Focus and Ten-Slide Kit

The M162C-2L-PB10 monocular biological microscope kit combines upper and lower LED illumination, coarse and fine focusing, and two widefield eyepieces. A ten-slide kit with five prepared specimens and five blank slides helps students start observing translucent specimens and larger opaque objects.

Key Features

• Use the lower transmitted light for translucent slide specimens, or the upper incident light for suitable opaque objects.
• A 45-degree inclined monocular head swivels through 360 degrees for a comfortable viewing position.
• Coarse and fine focus controls are available on both sides.
• Coated optical glass elements and a metal frame provide the microscope’s optical and mechanical structure.
• A plain stage with clips holds slides, while a six-hole disc diaphragm adjusts illumination.

Specifications

• Model: M162C-2L-PB10
• Eyepieces: WF10X and WF25X
• Objectives: 4X, 10X and spring-loaded 40X
• Condenser: single lens, 0.65 NA, with six-hole disc diaphragm
• Illumination: upper and lower LED; listed LED power 1W
• Power options: included 110V 60Hz outlet adapter or three included AA batteries
• Recommended age: 10 years and older

Package Contents

One monocular microscope with three objectives and top and bottom lights, one WF10X eyepiece, one WF25X eyepiece, one dust cover, two clips, one outlet power adapter, three AA batteries and a ten-piece slide kit containing five prepared specimens and five blank slides.

Power and Use

Use a suitable 110V 60Hz outlet with the included adapter, or use the battery compartment for AA operation. The adapter’s plug shape and output rating are not specified. This is an optical microscope kit without a digital camera or software connection.
